The OTTO Trim Switch is a low level, double pole trim switch with momentary action - Ideal for aircraft use. OTTO U2-652 Trim Switches provide poles that can be operated separately. The center-off, 3-position momentary trim switch offers 5 amps resistive @ 28VDC. KEY FEATURES • MIL-DTL-83731 Sealed • Rating: 5 Amps Resistive @ 28VDC • MIL-DTL-3950 Approved The OTTO U2-652 Trim Switches (Low Level) is in accordance with MIL-DTL-3950 & features the OTTO B2 Basic Switches.
OTTO U2-652 LOW LEVEL TRIM SWITCHES
The OTTO U2-652 Trim Switches are low level, double pole trim switches with momentary action. Featuring the OTTO B2 Basic Switches - Ideal for aircraft use.
The poles can be operated separately with a center-off, 3-position momentary action. The OTTO
Low Level Trim Switches provide 5 amps resistive @
28VDC.
Features:
Low Level Switching
Double Pole
Momentary Action
3-Positon with Centre-Off
MIL-DTL-3950 Approved
Bushing in accordance with MIL-DTL-3950
Stainless steel with lusterless finish
Specifications:
Rating: 5 Amps Resistive @ 28VDC
Sealed: Per MIL-DTL-83731 & Watertight to IP68S
Push Force: 13.0 (58 N) +/- 50%
Pull Force: 6.1 (27 N) +/- 50%
Electrical Life: 200,000 cycles
Materials:
Button: Aluminum alloy, red anodized
Housing: Aluminum alloy, black anodized
